FG-200E Overview
FG-200E is the Fortinet NGFW Middle-range Series FortiGate 200E firewall. The FortiGate 200E series delivers next generation firewall capabilities for mid-sized to large enterprises, with the flexibility to be deployed at the campus or enterprise branch.
Quick Spec
Table 1 shows the quick spec.
|
Sku |
FG-200E |
|
Firewall |
20 Gbps |
|
IPS |
2.2 Gbps |
|
NGFW |
1.8 Gbps |
|
Threat Protection |
1.2 Gbps |
|
Interfaces |
2x GE RJ45 Management/HA Ports 2x GE RJ45 WAN Ports 14x GE RJ45 Ports 4x GE SFP Slots |
Product Details
Figure 1 shows the front view of FG-200E.
Note:
|
① |
Console Port |
|
② |
USB Port |
|
③ |
2x GE RJ45 Management/HA Ports |
|
④ |
2x GE RJ45 WAN Ports |
|
⑤ |
10x GE RJ45 Ports |
|
⑥ |
4x GE RJ45 Ports |
|
⑦ |
4x GE SFP Slots |
Figure 2 shows the rear view of FG-200E.
The Optional Accessories & Spares
Table 2 shows the optional accessories or spares of FG-200E.
|
Optional Accessories & Spares |
SKU |
Description |
|
1 GE SFP LX Transceiver Module |
1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots |
|
|
1 GE SFP RJ45 Transceiver Module |
1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots |
|
|
1 GE SFP SX Transceiver Module |
1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots |
|
|
External redundant AC power supply |
External redundant AC power supply for up to 4 units: FG-100/101E, FG-300C, FG-310B, FS-348B and FS-448B. Up to 2 units: FG-200B, FG-200D, FG-200/201E, FG-240D and FG-300D, FG-400D, FG-500D, FG-600D, FHV-500D, FDD-200B, FDD-400B, FDD-600B and FDD-800B. |
Related Products
Table 3 shows the bundle models and licenses of FG-200E.
| Types | Model | Description |
| Basic Firewall | FG-200E | 18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated. |
| 1 year bundle | FG-200E-BDL-950-12 | FG-200E Hardware plus 1 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-200E & FC-10-00207-950-02-12) |
| 1 year License | FC-10-00207-950-02-12 | 1 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-200E |
| 3 year bundle | FG-200E-BDL-950-36 | FG-200E Hardware plus 3 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-200E & FC-10-00207-950-02-36) |
| 3 year License | FC-10-00207-950-02-36 | 3 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-200E |
| 5 year bundle | FG-200E-BDL-950-60 | FG-200E Hardware plus 5 Year 24*7 FortiCare and FortiGuard Unified (UTM) Protection (FG-200E & FC-10-00207-950-02-60) |
| 5 year License | FC-10-00207-950-02-60 | 5 year Unified (UTM) Protection (24x7 FortiCare plus Application Control, IPS, AV, Web Filtering and Antispam, FortiSandbox Cloud) of FG-200E |
Compare to Similar Item
Table 4 shows the comparison of FG-200E and FG-201E.
|
Sku |
FG-200E |
|
|
Firewall |
20 Gbps |
20 Gbps |
|
IPS |
2.2 Gbps |
2.2 Gbps |
|
NGFW |
1.8 Gbps |
1.8 Gbps |
|
Threat Protection |
1.2 Gbps |
1.2 Gbps |
|
Interfaces |
2x GE RJ45 Management/HA Ports 2x GE RJ45 WAN Ports 14x GE RJ45 Ports 4x GE SFP Slots |
2x GE RJ45 Management/HA Ports 2x GE RJ45 WAN Ports 14x GE RJ45 Ports 4x GE SFP Slots |
|
Local Storage |
— |
1x 480 GB SSD |
Get More Information
Do you have any question about the FG-200E?
Contact us now via Live Chat or info@falcon-atlantic.net
FG-200E Specification
FG-200E Specification |
|
|
Type |
FORTIGATE 200E |
|
Interfaces and Modules |
|
|
GE SFP Slots |
4 |
|
GE RJ45 Interfaces |
14 |
|
GE RJ45 WAN Interfaces |
2 |
|
GE RJ45 Management/HA Ports |
2 |
|
USB Ports |
2 |
|
RJ45 Console Port |
1 |
|
Local Storage |
- |
|
Included Transceivers |
0 |
|
System Performance and Capacity |
|
|
Firewall Throughput (1518 / 512 / 64 byte, UDP) |
20 / 20 / 9 Gbps |
|
Firewall Latency (64 byte, UDP) |
3 μs |
|
Firewall Throughput (Packet per Second) |
13.5 Mpps |
|
Concurrent Sessions (TCP) |
2 Million |
|
New Sessions/Second (TCP) |
135,000 |
|
Firewall Policies |
10,000 |
|
IPsec VPN Throughput (512 byte) |
7.2 Gbps |
|
Client-to-Gateway IPsec VPN Tunnels |
10,000 |
|
SSL-VPN Throughput |
900 Mbps |
|
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
5,00 |
|
SSL Inspection Throughput (IPS, avg. HTTPS) |
820 Mbps |
|
SSL Inspection CPS (IPS, avg. HTTPS) |
1000 |
|
Application Control Throughput (HTTP 64K) |
3.5 Gbps |
|
CAPWAP Throughput (1444 byte, UDP) |
1.5 Gbps |
|
Virtual Domains (Default / Maximum) |
10 / 10 |
|
Maximum Number of FortiSwitches Supported |
24 |
|
Maximum Number of FortiAPs (Total / Tunnel) |
128 / 64 |
|
Maximum Number of FortiTokens |
5,000 |
|
Maximum Number of Registered FortiClients |
600 |
|
High Availability Configurations |
Active-Active, Active-Passive, Clustering |
|
System Performance — Enterprise Traffic Mix |
|
|
IPS Throughput |
2.2 Gbps |
|
NGFW Throughput |
1.8 Gbps |
|
Threat Protection Throughput |
1.2 Gbps |
|
Dimensions and Power |
|
|
Height x Width x Length |
1.75 x 17.0 x 11.9 inches 44.45 x 432 x 301 mm |
|
Form Factor |
1 RU |
|
AC Power Supply |
100–240V AC, 60–50 Hz |
|
Power Consumption (Average / Maximum) |
70.98 / 109.9 W |
|
Heat Dissipation |
374.9 BTU/h |
|
Operating Environment and Certifications |
|
|
Operating Temperature |
32–104°F (0–40°C) |
|
Storage Temperature |
-31–158°F (-35–70°C) |
|
Humidity |
10–90% non-condensing |
|
Noise Level |
31.1 dBA |
|
Operating Altitude |
Up to 7,400 ft (2,250 m) |
|
Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
|
Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 |
