UAP-AC-LITE Overview
Featuring an ultra-compact design, the UniFi AC Lite AP delivers a cost-effective combination of value and performance in a reduced footprint: 25% smaller than the standard UniFi AP. The UniFi AC Lite AP provides simultaneous, dual-band, 2x2 MIMO technology and is available in single- and five‑packs2.
Quick Specs
Table 1 shows the Quick Specs
|
SKU |
UAP-AC-LITE |
|
Dimensions |
160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24") |
|
Networking Interface |
(1) 10/100/1000 Ethernet Port |
|
Ports |
No |
|
Buttons |
Reset |
|
Antennas |
(2) Dual-Band Antennas, 3 dBi Each |
|
Wi-Fi Standards |
802.11 a/b/g/n/ac |
|
Power Method |
Passive Power over Ethernet (24V), (Pairs 4, 5+; 7, 8 Return) |
|
Power Supply |
24V, 0.5A Gigabit PoE Adapter |
|
Maximum Power Consumption |
6.5W |
Product Details
UAP-AC-LITE provides these features:
① Save Money and Save Time
Unlike traditional enterprise Wi-Fi systems that use a hardware controller, UniFi comes bundled with a non-dedicated software controller that can be deployed on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service.
② Powerful Hardware
The UniFi 802.11AC Dual-Radio Aps feature the latest in Wi-Fi 802.11AC MIMO technology. Intuitive UniFi Controller Software Configure and manage your APs with the easy-to-learn user interface.
③ Expandable Unlimited scalability
Build wireless networks as big or small as needed. Start with one (or upgrade to a three‑pack) and expand to thousands while maintaining a single unified management system.
Table 2 shows the supported switches.
|
Product Name |
Details |
|
UBNT UniFi US-8 Enterprise PoE 8-Port Managed PoE Gigabit Switch |
|
|
UBNT US-8-60W UniFi 8-Port Gigabit PoE Compliant Managed Switch, Enterprise |
|
|
UBNT UniFi US-8-150W Enterprise PoE 8-Port Managed PoE Gigabit Switch |
|
|
UBNT UniFi US-16-150W Enterprise PoE 16-Port Managed PoE Gigabit Switch |
|
|
UBNT US-24 UniFi 24-Port Gigabit PoE Compliant Managed Switch, Enterprise |
|
|
UBNT UniFi US-24-250W Enterprise PoE 24-Port Managed PoE Gigabit Switch |
Compare to Similar Items
Table 3 shows the comparison.
|
Product Name |
UAP-AC-LITE |
||
|
Dimensions |
160 x 31.45 mm |
139.7 x 86.7 mm |
196.7 x 35 mm |
|
Environment |
Indoor |
Indoor |
Indoor/Outdoor |
|
2.4 GHz Radio Rate |
300 Mbps |
300 Mbps |
450 Mbps |
|
5 GHz Radio Rate |
867 Mbps |
867 Mbps |
1300 Mbps |
|
PoE Mode |
802.3af/A PoE & 24V PoE |
802.3at PoE+ |
802.3af PoE/802.3at PoE+ |
|
Ports |
(1)10/100/1000 Ethernet |
(3)10/100/1000 Ethernet |
(2)10/100/1000 Ethernet |
Get More Information
Do you have any question about the UAP-AC-LITE?
Contact us now via Live Chat or info@falcon-atlantic.net
UAP-AC-LITE Specification
UAP-AC-LITE Specification |
|
|
Dimensions |
160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24") |
|
Networking Interface |
(1) 10/100/1000 Ethernet Port |
|
Ports |
No |
|
Buttons |
Reset |
|
Antennas |
(2) Dual-Band Antennas, 3 dBi Each |
|
Wi-Fi Standards |
802.11 a/b/g/n/ac |
|
Power Method |
Passive Power over Ethernet (24V), (Pairs 4, 5+; 7, 8 Return) |
|
Power Supply |
24V, 0.5A Gigabit PoE Adapter |
|
Maximum Power Consumption |
6.5W |
|
Max TX Power |
20 dBm |
|
BSSID |
Up to Four per Radio |
|
Power Save |
Supported |
|
Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
|
Certifications |
CE, FCC, IC |
|
Mounting |
Wall/Ceiling (Kits Included) |
|
Operating Temperature |
-10 to 70° C (14 to 158° F) |
|
Operating Humidity |
5 to 95% Noncondensing |
|
ADVANCED TRAFFIC MANAGEMENT |
|
|
VLAN |
802.1Q |
|
Advanced QoS |
Per-User Rate Limiting |
|
Guest Traffic Isolation |
Supported |
|
WMM |
Voice, Video, Best Effort, and Background |
|
Concurrent Clients |
200+ |
|
SUPPORTED DATA RATES (MBPS) |
|
|
802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
|
802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
|
802.11ac |
6.5 Mbps to 867 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) |
|
802.11b |
1, 2, 5.5, 11 Mbps |
|
802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
