UBNT

UAP-AC-IW with Gigabit PoE Power Supply

Sale
Regular price $149.00

Tax included.

UAP-AC-IW with Gigabit PoE Power Supply Overview

The UniFi AC In-Wall AP transforms an Ethernet wall connection into a dual-band 802.11AC Wi-Fi Access Point. It features two Gigabit Ethernet ports, one of which delivers PoE to power and connects an 802.3af device to the network.

Quick Specs

Table 1 shows the Quick Specs.

SKU	UAP-AC-IW with Gigabit PoE Power Supply
Dimensions	139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01")
Networking Interface	(3) 10/100/1000 Ethernet Ports
Button(s)	Reset
Power Method	802.3at PoE+ Supported
Power Supply	UniFi Switch (PoE)
Power Save	Supported
PoE Out	48V Passthrough (Pins 1, 2+; 3, 6-)
2.4 GHz Radio Rate	300 Mbps

Product Details

UAP-AC-IW with Gigabit PoE Power Supply provides these features:

① Simultaneous Dual-Band 802.11ac Access Point

② Internal 802.3at Gigabit Ethernet Port for Data + PoE In

③ External Gigabit Ethernet Port for Data + 48V PoE Out*

④ External Gigabit Ethernet Port for Data Only

⑤ Mounts in 1-Gang Electrical Wall Box

⑥ Managed by UniFi Controller Software

Table 2 shows the supported switches.

Product Name	Details
US-8	UBNT UniFi US-8 Enterprise PoE 8-Port Managed PoE Gigabit Switch
US-8-60W	UBNT US-8-60W UniFi 8-Port Gigabit PoE Compliant Managed Switch, Enterprise
US-8-150W	UBNT UniFi US-8-150W Enterprise PoE 8-Port Managed PoE Gigabit Switch
US-16-150W	UBNT UniFi US-16-150W Enterprise PoE 16-Port Managed PoE Gigabit Switch
US-24	UBNT US-24 UniFi 24-Port Gigabit PoE Compliant Managed Switch, Enterprise
US-24-250W	UBNT UniFi US-24-250W Enterprise PoE 24-Port Managed PoE Gigabit Switch

Compare to Similar Items

Table 3 shows the comparison.

Product Name	UAP-AC-IW with Gigabit PoE Power Supply	UAP-AC-LITE	UAP-AC-PRO
Dimensions	139.7 x 86.7mm	160 x 31.45 mm	196.7 x 35 mm
Environment	Indoor	Indoor	Indoor/Outdoor
2.4 GHz Radio Rate	300 Mbps	300 Mbps	450 Mbps
5 GHz Radio Rate	867 Mbps	867 Mbps	1300 Mbps
PoE Mode	802.3at PoE+	802.3af/A PoE & 24V PoE	802.3af PoE/802.3at PoE+
Ports	(3)10/100/1000 Ethernet	(1)10/100/1000 Ethernet	(2)10/100/1000 Ethernet

Get More Information

Do you have any question about the UAP-AC-IW with Gigabit PoE Power Supply?

UAP-AC-IW with Gigabit PoE Power Supply Specification

UAP-AC-IW with Gigabit PoE Power Supply Specification
Dimensions	139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01")
Networking Interface	(3) 10/100/1000 Ethernet Ports
Button(s)	Reset
Power Method	802.3at PoE+ Supported
Power Supply	UniFi Switch (PoE)
Power Save	Supported
PoE Out	48V Passthrough (Pins 1, 2+; 3, 6-)
Max. Power Consumption with PoE Passthrough	7W 19W*
Max. TX Power 2.4 GHz 5 GHz	20 dBm 20 dBm
MIMO 2.4 GHz 5 GHz	2 x 2 2 x 2
Max. Data Speed 2.4 GHz 5 GHz	300 Mbps 866.7 Mbps
Max. Range	100 m (328')
Antennas	(1) Dual-Band Antenna, Single-Polarity
Antenna Gain 2.4 GHz 5 GHz	1 dBi 2 dBi
Wi-Fi Standards	802.11 a/b/g/n/ac
Wireless Security	WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Mounting	1-Gang Electrical Wall Box (Not Included)
Operating Temperature	-10 to 50° C (14 to 122° F)
Operating Humidity	5 to 95% Noncondensing
Certifications	CE, FCC, IC
