Inspur HF18000G5 Storage Overview

Check Inspur All Servers

View the overview of Inspur rack servers, tower servers and more products, and select the best one for your business.

• Inspur Rack Servers • Inspur Tower Servers • All Servers

Learn Details

Inspur HF18000G5 high-end all-flash storage system is a medium and large-sized enterprise oriented to structured and unstructured.

Quick Spec

Table 1 shows the quick spec.

Model	HF18000G5
Controller	Multi-controller (Active-Active), with 2 controllers as standard, support up to 48
cache	System cache supports up to 650TB
capacity	Maximum capacity up to 100PB
IOPS	Up to 15,000,000
Hard disk type	NVMe SSD，SAS SSD
Number of hard drives	Support 13824 hard drives
Host interface	The system supports a maximum of 1,056 host interfaces, and the system supports a maximum of 256 host interfaces
Extension ports	12Gb SAS3.0 expansion interface, the system supports a maximum of more than 9,216Gb / s disk channel interface rate
Expansion cabinet	2U24 (NVMe), 2U24 (SAS), 4U60 (3.5 inches)
RAID level	0、1、10、5、6、50、60、6-FR

Product Details

Inspur HF18000G5 provides these features:

- Active-Active architecture: Inspur HF-G5 high-end all-flash storage adopts the industry-leading Active-Active storage architecture, of which the HF18000G5 controller uses a multi-controller PCIe exchange loosely coupled architecture and a fully modular design to achieve the load between the controllers Balance, eliminate the performance bottleneck of the controller, improve system high availability, and ensure business continuity.

- Scale-Out architecture: Inspur HF18000G5 high-end full-flash active storage supports online horizontal expansion, supports up to 16 controllers, and TB-level caches, enabling customers 'storage resources to grow linearly to meet the changing needs of customers' businesses.

- High storage availability: Inspur HF18000G5 high-end full-flash active storage uses a fully redundant architecture, full modularity, redundant cache, redundant power supply fans, and dual-active controller design. The main components have no single point of failure, support online hardware expansion, online firmware upgrade, online system maintenance, and support for abnormal power failure data protection.

- Unified software platform: Based on the unified software platform, data can be freely migrated between storages. By replacing the controller, the HF18000G5 can realize the upgrade from low-end products to high-end products, and no data migration is required during the upgrade process.

Get More Information

Do you have any question about the HF18000G5?

Inspur HF18000G5 Storage Specification

HF18000G5 Specification
Controller	Multi-controller (Active-Active), with 2 controllers as standard, support up to 48
cache	System cache supports up to 650TB
capacity	Maximum capacity up to 100PB
IOPS	Up to 15,000,000
Hard disk type	NVMe SSD，SAS SSD
Number of hard drives	Support 13824 hard drives
Host interface	The system supports a maximum of 1,056 host interfaces, and the system supports a maximum of 256 host interfaces
Extension ports	12Gb SAS3.0 expansion interface, the system supports a maximum of more than 9,216Gb / s disk channel interface rate
Expansion cabinet	2U24 (NVMe), 2U24 (SAS), 4U60 (3.5 inches)
RAID level	0、1、10、5、6、50、60、6-FR
Advanced Features	Storage active-active, data snapshot function, local replication of data volumes, thin provisioning, automatic data tiering, cache partitioning, dynamic allocation of QoS performance resources, remote volume replication (synchronous / asynchronous), dynamic expansion of logical partitions, advanced deep performance, monitoring Manage SQL and exchange application data recovery oriented function
Size	Switch cabinet: 482 × 816 × 218mm 5U; Controller cabinet: 482 × 788 × 133mm 3U;
Power consumption	NVMe hard disk enclosure: 482 × 540 × 88mm 2U; SAS hard disk enclosure: 482 × 540 × 88mm 2U
Working environment	Switch cabinet: 560W; Controller cabinet: 1,560W; NVMe hard disk cabinet: 420W;
