FG-2500E Overview
The FortiGate 2500E delivers high performance threat protection and SSL inspection for large enterprises and service providers, with the flexibility to be deployed at the enterprise/cloud edge, in the data center core or internal segments. The multiple high-speed interfaces, high port density, superior security efficacy and high throughput of the 2500E keeps your network connected and secure.
Quick Spec
Table 1 shows the quick spec of FG-2500E.
|
Model |
FG-2500E |
|
Firewall |
150 Gbps |
|
IPS |
11.5 Gbps |
|
NGFW |
9 Gbps |
|
Threat Protection |
5.4 Gbps |
Product Details
Figure 1 shows the ports of FG-2500E.
Note:
|
① |
Console Port |
④ |
32x GE RJ45 Ports |
|
② |
USB Port |
⑤ |
10x 10 GE SFP+ Slots |
|
③ |
2x GE RJ45 Management Ports |
⑥ |
2x 10 GE SFP+ SR (LC Connector, bypass) |
FG-2500E provides these features:
Security
· Identifies thousands of applications inside network traffic for deep inspection and granular policy enforcement
· Protects against malware, exploits, and malicious websites in both encrypted and non-encrypted traffic
· Prevent and detect against known and unknown attacks using continuous threat intelligence from AI powered FortiGuard Labs security services
Performance
· Delivers industry’s best threat protection performance and ultra-low latency using purpose-built security processor (SPU) technology
· Provides industry-leading performance and protection for SSL encrypted traffic
Certification
· Independently tested and validated best security effectiveness and performance
· Received unparalleled third-party certifications from NSS Labs
Networking
· Delivers advanced networking capabilities that seamlessly integrate with advanced layer 7 security and virtual domains (VDOMs) to offer extensive deployment flexibility, multi-tenancy and effective utilization of resources
· Delivers high-density, flexible combination of various highspeed interfaces to enable best TCO for customers for data center and WAN deployments
Management
· Includes management console that is effective, simple to use, and provides comprehensive network automation & visibility.
· Provides Zero Touch Integration with Security Fabric’s Single Pane of Glass Management
· Predefined compliance checklist analyzes the deployment and highlights best practices to improve overall security posture
Security Fabric
· Enables Fortinet and Fabric-ready partners’ products to provide broader visibility, integrated end-to-end detection, threat intelligence sharing and automated remediation
Compare to Similar Item
Table 2 shows the comparison.
|
Model |
FG-2500E |
|
|
Firewall |
160 Gbps |
150 Gbps |
|
NGFW |
21 Gbps |
9 Gbps |
|
Threat Protection |
17 Gbps |
5.4 Gbps |
|
Interfaces |
4x 40GE QSFP+ slots, 16x 25GE SFP28 / 10GE SFP+ slots (including 14x ports, 2x HA ports), 14x GE RJ45 ports (including 12x ports, 2x management ports), 4x 10GBase-T ports |
Multiple GE RJ45, 10 GE SFP+ slots and Bypass 10 GE SFP+ ports |
Get More Information
Do you have any question about the FG-2500E?
Contact us now via Live Chat or info@falcon-atlantic.net
FG-2500E Specification
FG-2500E Specification |
|
|
Interfaces and Modules |
|
|
Hardware Accelerated 10 GE SFP+ Slots |
10 + 2 bypass |
|
Hardware Accelerated GE RJ45 Ports |
32 |
|
GE RJ45 Management / HA Ports |
2 |
|
USB Ports |
1 |
|
Console Port |
1 |
|
Internal Storage |
1x 480 GB SSD |
|
Included Transceivers |
2x SFP+ (SR 10GE) |
|
System Performance — Enterprise Traffic Mix |
|
|
IPS Throughput 2 |
11.5 Gbps |
|
NGFW Throughput 2, 4 |
9 Gbps |
|
Threat Protection Throughput 2, 5 |
5.4 Gbps |
|
System Performance and Capacity |
|
|
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
150 / 150 / 95 Gbps |
|
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) |
150 / 150 / 95 Gbps |
|
Firewall Latency (64 byte, UDP) |
2 μs |
|
Firewall Throughput (Packet per Second) |
145.5 Mpps |
|
Concurrent Sessions (TCP) |
20 Million |
|
New Sessions/Second (TCP) |
500,000 |
|
Firewall Policies |
100,000 |
|
IPsec VPN Throughput (512 byte) |
95 Gbps |
|
Gateway-to-Gateway IPsec VPN Tunnels |
20,000 |
|
Client-to-Gateway IPsec VPN Tunnels |
100,000 |
|
SSL-VPN Throughput |
6 Gbps |
|
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
30,000 |
|
SSL Inspection Throughput (IPS, avg. HTTPS) |
9.4 Gbps |
|
SSL Inspection CPS (IPS, avg. HTTPS) |
5,500 |
|
SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
2 Million |
|
Application Control Throughput (HTTP 64K) |
20 Gbps |
|
CAPWAP Throughput (1444 byte, UDP) |
21 Gbps |
|
Virtual Domains (Default / Maximum) |
10 / 500 |
|
Maximum Number of FortiSwitches Supported |
128 |
|
Maximum Number of FortiAPs (Total / Tunnel) |
4,096 / 1,024 |
|
Maximum Number of FortiTokens |
20,000 |
|
Maximum Number of Registered FortiClients |
20,000 |
|
High Availability Configurations |
Active-Active, Active-Passive, Clustering |
|
Dimensions and Power |
|
|
Height x Width x Length (inches) |
3.5 x 17.4 x 21.9 |
|
Height x Width x Length (mm) |
88 x 442 x 555 |
|
Form Factor |
Rack Mount, 2 RU |
|
Power |
|
|
AC Power Supply |
100–240V AC, 50–60 Hz |
|
Maximum Current |
9A |
|
Power Consumption (Average / Maximum) |
312 W / 470 W |
|
Heat Dissipation |
1,604 BTU/h |
|
Redundant Power Supplies |
Yes, Hot Swappable |
|
Operating Environment and Certifications |
|
|
Operating Temperature |
32–104°F (0–40°C) |
|
Storage Temperature |
-31–158°F (-35–70°C) |
|
Humidity |
10–90% non-condensing |
|
Noise Level |
58 dBA |
|
Operating Altitude |
Up to 7,400 ft (2,250 m) |
|
Compliance |
FCC Part 15 Class A, C-Tick, VCCI, CE, UL/cUL, CB |
|
Certifications |
ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN |
